Sponsored announcement / CNC
ToolDance introduces
The X1
desktop CNC.
Nine tools. A 1,500-watt spindle.
Optional 4-axis and 5-axis modules.
Automatic tool changes and an expandable machining system, built into an enclosed desktop design.
Explore the X1Scroll to see inside
Enclosed three-axis CNC
Manufacturer rendering
Spindle, worktable & tool magazine
Manufacturer cutaway rendering
ToolDance sponsored this announcement and supplied the product information and media. I haven’t tested the X1.
ToolDance unveiled the X1 at IFA in Berlin in September 2026, with a Kickstarter launch planned for mid-October 2026. Aimed at makers, engineers, and small businesses, the three-axis machine combines automatic tool changes and a 3D sensing system in one enclosure, with an optional 4-axis module and an optional 5-axis module. Company announcement ↗ Launch update ↗
X1 questions: price, software, materials, and setup →
Nine tools, with automatic changes
The X1’s automatic changer holds nine tools and switches between them during a programmed job. A larger end mill can remove material, a smaller cutter can handle fine details, and drilling or edge finishing can use additional tools.
ToolDance pairs the magazine with RFID tool recognition and support for compatible standard end mills with shanks up to 10 mm. ToolDance brief ↗
I like the flexibility this offers for custom brackets, fixtures, and enclosures. Several cutters can be loaded for one job, covering pockets, holes, and finished edges with fewer manual tool changes.
See ToolDance StudioToolDance Studio
ToolDance Studio is the company’s software for preparing and running X1 jobs. ToolDance describes STEP and STL import, design checks, automatic toolpaths for supported jobs, workholding guidance, editable machining operations, and simulation. ToolDance brief ↗
I reviewed the software demonstration videos supplied by ToolDance. They show toolpath previews and cutting simulation, design checks that highlight potential machining difficulties, and on-screen workholding guidance paired with a person positioning and securing stock. Supplied Studio demonstrations ↗
These demonstrations suggest Studio could make CNC preparation easier to follow. I hope to have the opportunity to test the full workflow firsthand, from importing a model through setup and machining, and share what I learn in a future update.
IFA Berlin / September 2026
Inside the X1’s
cutting area.
The spindle, workholding, and cutting area
on display at IFA Berlin.
A 1,500-watt spindle and a cast‑aluminum frame
At the center of the X1 is a permanent magnet synchronous motor (PMSM) spindle with a maximum speed of 24,000 RPM. ToolDance specifies rated spindle power: 1.5 kW (S1). This is a manufacturer rating; ToolDance does not specify it as mechanical output power. ToolDance specifies a cast-aluminum-alloy frame and emphasizes the spindle’s torque at lower speeds. ToolDance brief ↗ Spindle rating ↗
ToolDance lists steel, stainless steel, titanium, aluminum, brass, copper, hardwood, acrylic, and other plastics among the X1’s supported materials, positioning the machine as a versatile platform for machining a wide range of metals and non-metal materials. ToolDance product details ↗
The work envelope measures 400 × 265 × 180 mm—roughly 15.75 × 10.43 × 7.09 inches. Available part space depends on the installed cutter, fixture, and any optional 4-axis or 5-axis module.
Air blast standard, flood cooling optional
Air blast is standard for dry cutting. ToolDance lists crowdfunding add-on prices of $799 for its flood-cooling module and $499 for its dust collection and filtration module. Both are optional. ToolDance product details ↗
±0.01 mm
ToolDance specifies ±0.01 mm positioning repeatability: the ability to return to the same position. Finished-part tolerances depend on the machining process. Measurement definitions ↗
Built-in cameras and a workpiece probe
The X1 houses its spindle and tool magazine inside an enclosure with a locking door and safety interlock. ToolDance’s 3D sensing system pairs a spindle-mounted RGB camera and line-laser sensor with a workpiece probe, and a separate 1080p camera streams the job for remote monitoring. ToolDance specifications ↗
ToolDance says the system recognizes its own stock and fixtures and supports fully automatic, semi-automatic, and manual workpiece setup. The company also describes guided setup after an operator turns a part over to machine another side.
Locating the material is an important part of CNC preparation. The machine needs work coordinates that match the physical setup so it can place the programmed cuts correctly. Milling setup documentation ↗
Optional 4-axis and 5-axis modules
The X1 starts with three-axis machining. Its optional 4-axis module and optional 5-axis module add rotary motion for cylindrical work and parts with features at several angles. ToolDance brief ↗
The modular design gives makers a choice of configurations for different projects. ToolDance describes the three-axis setup as offering the largest work area and greatest stiffness, while the 5-axis module adds access to more complex shapes.
All module prices are US-dollar crowdfunding add-on prices confirmed by ToolDance on September 28, 2026, separate from the base machine. They are not retail prices. ToolDance product details ↗
X1 Market Comparison
The X1 changes between nine stored tools automatically. That matters when a part needs several cutters. Here’s how its announced $2,999 starting price and specifications compare with 8 desktop CNC alternatives.
ClickTap a machine to compare it with the ToolDance X1
USD · Prices reviewed October 1, 2026 · Specifications checked September 23, 2026
Makera’s October 1 prices replace its September pre-sale and sale offers. Carvera and Carvera Air now have Anniversary Sale Encore pricing; Z1 and Z1 Pro show their standalone retail prices. Follow each manufacturer link for current terms.
ToolDance X1 vs NestWorks C500
ToolDance X1
ANNOUNCED
Announced Super Early Bird
- Automatic Tool Changer Capacity+ 1 workpiece probe
- 9 tools
- Optional 4-axis and 5-axis modules
- 3 axes
NestWorks C500
PREORDER
Preorder advertised · checkout price not public
- Automatic changes
- 5 tools
- Optional fourth axis
- 3 axes
- X/Y travel area
X1 has about 2.1× the C500’s full X/Y travel area
- X1
- 400 × 265 mm envelope
- C500
- 240 × 210 mm full travel
- Published spindle ratings
X1 has a 1.5 kW (S1) spindle rating
- X1
- 1.5 kW (S1) · rated power
- C500
- 800 W · basis not stated
- Automatic tool positions
X1 holds 4 more cutting tools
- X1
- 9 tools
- C500
- 5 tools
About 2.1 times the C500’s full X/Y travel area, a 1,500 W spindle rating, and four more tools
Both machines change tools automatically. The X1’s 400 × 265 mm X/Y envelope is about 2.1 times the C500’s full 240 × 210 mm travel area. The C500’s magazine reduces usable X/Y area, and NestWorks’ product page publishes conflicting installed-magazine dimensions. ToolDance specifies rated spindle power of 1.5 kW (S1); NestWorks lists 800 W without the same duty basis. The X1 holds nine cutting tools against five. The C500 includes MQL mist cooling; the X1 has standard air blast and optional flood coolant.
Price context: The C500’s $4,699 is its stated MSRP from the ended Kickstarter. NestWorks now advertises pre-orders, but its linked store does not expose a public checkout price. The X1’s $2,999 is an announced campaign price against a stated $5,999 MSRP.
Compare all 12 specifications
| Specification | ToolDance X1 | NestWorks C500 |
|---|---|---|
| Price and buying stage | $2,999 announced Super Early Bird; $2,799 for eligible VIP reservation holders after cashback; $5,999 stated MSRP. Kickstarter planned for mid-October 2026. The official campaign page remained in prelaunch, and the $30 reservation was marked out of stock, when checked October 1. Optional modules have separate crowdfunding add-on prices; final bundle and delivery terms are still to come. | Manufacturer-stated MSRP: $4,699 in the ended Kickstarter. NestWorks now advertises pre-orders, but its linked store is password-protected and exposes no current checkout price. Kickstarter backers paid $2,799 to $3,199; late pledges closed July 28, 2026. |
| Work area | 400 × 265 × 180 mm work envelope (X × Y × Z) | 240 × 210 × 130 mm full XYZ travel. The tool magazine reduces usable X/Y area; NestWorks’ product page publishes conflicting installed-magazine dimensions. |
| Spindle | Rated spindle power: 1.5 kW (S1); PMSM, up to 24,000 rpm; shanks up to 10 mm. Not specified as mechanical output power. | 800 W, 9,000–18,000 rpm; shanks up to 1/4 in |
| Tool changing | Automatic: 9 tools plus a workpiece probe; RFID tool identification | Automatic: 5 tools; RFID tool holders |
| Probing and sensing | Spindle RGB camera and line-laser sensor, workpiece probe, and a 1080p monitoring camera | 3D touch probe, automatic tool setter, probing camera, and laser distance sensor |
| Axes | 3-axis standard; optional 4-axis module ($699) or 5-axis module ($1,099), both crowdfunding add-on prices. 5-axis development preview: workpieces up to 80 × 114 × 92 mm in 3+2 machining, or 80 × 80 × 80 mm in simultaneous 5-axis machining. | 3-axis standard; optional 4th axis ($699 MSRP); no 5-axis option |
| Cooling | Air blast standard; optional flood-cooling module ($799 crowdfunding add-on) | MQL mist standard; air blast with a buyer-supplied compressor; no flood option |
| Enclosure and dust | Fully enclosed with a locking door; optional dust collection and filtration module ($499 crowdfunding add-on) | Fully enclosed with an interlocked door (IP54); auger chip evacuation and a vacuum port |
| Motion system | Preloaded ball screws; closed-loop NEMA 23 steppers | Ball screws and linear rails; closed-loop NEMA 23 steppers |
| Weight and footprint | 100 kg; 750 × 625 × 772 mm | About 120–130 kg; 550 × 615 × 745 mm |
| Software | ToolDance Studio (automatic CAM and design checks) and ToolDance Controller | NestStudio with automatic toolpaths; accepts standard G-code |
| Warranty | 1 year | 12 months on main components |
ToolDance X1 vs Makera Carvera
ToolDance X1
ANNOUNCEDAnnounced Super Early Bird
- Automatic Tool Changer Capacity+ 1 workpiece probe
- 9 tools
- Optional 4-axis and 5-axis modules
- 3 axes
Makera Carvera
RETAIL
Anniversary Sale Encore · regular $5,799
- Automatic changes
- 6 tools
- Optional fourth axis
- 3 axes
- Published spindle ratings
X1 has a 1.5 kW (S1) spindle rating
- X1
- 1.5 kW (S1) · rated power
- Carvera
- 200 W · basis not stated
- Liquid coolant
X1 offers optional flood coolant
- X1
- Optional flood coolant module
- Carvera
- None listed; air assist needs a buyer-supplied compressor or pump
- Axis options
X1 offers an optional 5-axis module
- X1
- Optional 4-axis and 5-axis modules
- Carvera
- Optional fourth axis
A 1,500 W spindle rating, a flood coolant option, and an optional 5-axis module
Both machines change tools automatically; the X1 holds nine against Carvera’s six. ToolDance rates the X1’s spindle at 1,500 W against Carvera’s 200 W. Carvera offers air assist from a buyer-supplied compressor or pump and built-in dust collection, but Makera lists no liquid coolant option; the X1 offers an optional flood coolant module. Carvera’s axis options stop at a fourth axis, while ToolDance lists optional 4-axis and 5-axis modules, with the 5-axis module in development preview.
Price context: Carvera’s standalone Anniversary Sale Encore price is $5,299 (regular $5,799), checked October 1. The X1’s $2,999 is an announced campaign price. Its optional flood-cooling module costs $799 as a crowdfunding add-on; final bundle contents and delivery terms are still to come.
Compare all 12 specifications
| Specification | ToolDance X1 | Makera Carvera |
|---|---|---|
| Price and buying stage | $2,999 announced Super Early Bird; $2,799 for eligible VIP reservation holders after cashback; $5,999 stated MSRP. Kickstarter planned for mid-October 2026. The official campaign page remained in prelaunch, and the $30 reservation was marked out of stock, when checked October 1. Optional modules have separate crowdfunding add-on prices; final bundle and delivery terms are still to come. | $5,299 standalone Anniversary Sale Encore price when checked October 1 (regular $5,799). Available to order; confirm shipping timing with Makera. |
| Work area | 400 × 265 × 180 mm work envelope (X × Y × Z) | 360 × 240 × 140 mm |
| Spindle | Rated spindle power: 1.5 kW (S1); PMSM, up to 24,000 rpm; shanks up to 10 mm. Not specified as mechanical output power. | 200 W, up to 15,000 rpm; shanks up to 1/4 in |
| Tool changing | Automatic: 9 tools plus a workpiece probe; RFID tool identification | Automatic: 6 tools |
| Probing and sensing | Spindle RGB camera and line-laser sensor, workpiece probe, and a 1080p monitoring camera | Wireless probe for Z, tool length, and leveling; manual XYZ probe |
| Axes | 3-axis standard; optional 4-axis module ($699) or 5-axis module ($1,099), both crowdfunding add-on prices. 5-axis development preview: workpieces up to 80 × 114 × 92 mm in 3+2 machining, or 80 × 80 × 80 mm in simultaneous 5-axis machining. | 3-axis standard; optional 4th axis ($599); no 5-axis option |
| Cooling | Air blast standard; optional flood-cooling module ($799 crowdfunding add-on) | Optional air assist from a buyer-supplied compressor or pump; no liquid coolant option |
| Enclosure and dust | Fully enclosed with a locking door; optional dust collection and filtration module ($499 crowdfunding add-on) | Fully enclosed; built-in dust collection |
| Motion system | Preloaded ball screws; closed-loop NEMA 23 steppers | Ball screws; closed-loop servo motors |
| Weight and footprint | 100 kg; 750 × 625 × 772 mm | About 50 kg; 580 × 520 × 540 mm |
| Software | ToolDance Studio (automatic CAM and design checks) and ToolDance Controller | Makera Controller and Makera CAM; Makera Studio is in public beta. Built-in 2.5 W laser. |
| Warranty | 1 year | 1 year (US) |
ToolDance X1 vs InfiMaker K1
ToolDance X1
ANNOUNCEDAnnounced Super Early Bird
- Automatic Tool Changer Capacity+ 1 workpiece probe
- 9 tools
- Optional 4-axis and 5-axis modules
- 3 axes
InfiMaker K1
LATE PLEDGE
Earlier $5,199 offer ended Sept 26
- Automatic changes+ 1 probe slot
- 5 tools
- Simultaneous machining
- 5 axes
- X/Y travel area
X1 has about 3× the K1’s X/Y travel area
- X1
- 400 × 265 mm
- K1
- 220 × 160 mm
- Tool changer stations
X1 holds 4 more cutting tools
- X1
- 9 tools + probe
- K1
- 5 tools + probe
- Liquid coolant
Both offer optional liquid cooling
- X1
- Flood coolant ($799 crowdfunding add-on)
- K1
- Optional InfiFlow water coolant
About 3 times the K1’s X × Y travel and four more tool positions
The X1’s 400 × 265 × 180 mm envelope has about 3 times the K1’s 220 × 160 × 180 mm travel area in X and Y. That is different from the room for a part during five-axis machining: the K1 lists a 120 × 120 × 120 mm workpiece limit, against 80 × 80 × 80 mm for the X1’s optional module, which remains a development preview. The X1 holds nine cutting tools plus a probe, against five plus a probe on the K1. Both offer optional liquid cooling.
Price context: The X1 base plus 5-axis module totals $4,098 ($2,999 + $1,099) at announced crowdfunding prices, before other accessories, shipping, and taxes. K1 late pledges start at $5,699 with simultaneous five-axis machining included and delivery estimated for February 2027. These are different configurations, not identical equipment packages. The K1’s earlier $5,199 offer ended September 26.
Compare all 12 specifications
| Specification | ToolDance X1 | InfiMaker K1 |
|---|---|---|
| Price and buying stage | $2,999 announced Super Early Bird; $2,799 for eligible VIP reservation holders after cashback; $5,999 stated MSRP. Kickstarter planned for mid-October 2026. The official campaign page remained in prelaunch, and the $30 reservation was marked out of stock, when checked October 1. Optional modules have separate crowdfunding add-on prices; final bundle and delivery terms are still to come. | $5,699 late-pledge price (stated MSRP $9,499), with estimated delivery February 2027. The $5,199 Super Early Bird offer ended September 26. |
| Work area | 400 × 265 × 180 mm work envelope (X × Y × Z) | 220 × 160 × 180 mm XYZ travel; largest 5-axis workpiece 120 × 120 × 120 mm |
| Spindle | Rated spindle power: 1.5 kW (S1); PMSM, up to 24,000 rpm; shanks up to 10 mm. Not specified as mechanical output power. | 1.5 kW (maximum rating), up to 20,000 rpm; 4 and 6 mm shanks in the changer |
| Tool changing | Automatic: 9 tools plus a workpiece probe; RFID tool identification | Automatic: 5 tools plus a probe station |
| Probing and sensing | Spindle RGB camera and line-laser sensor, workpiece probe, and a 1080p monitoring camera | Wireless 3D touch probe for centering and 5-axis calibration |
| Axes | 3-axis standard; optional 4-axis module ($699) or 5-axis module ($1,099), both crowdfunding add-on prices. 5-axis development preview: workpieces up to 80 × 114 × 92 mm in 3+2 machining, or 80 × 80 × 80 mm in simultaneous 5-axis machining. | Simultaneous 5-axis included (B axis −30° to +110°, C axis 360°) |
| Cooling | Air blast standard; optional flood-cooling module ($799 crowdfunding add-on) | Optional InfiFlow water coolant; water-cooled spindle |
| Enclosure and dust | Fully enclosed with a locking door; optional dust collection and filtration module ($499 crowdfunding add-on) | Fully enclosed with a locking door; chip tray, no dust-collection port |
| Motion system | Preloaded ball screws; closed-loop NEMA 23 steppers | Preloaded ball screws and linear guides; servo motors |
| Weight and footprint | 100 kg; 750 × 625 × 772 mm | About 166 kg with the production cast-iron bed; 560 × 700 × 800 mm |
| Software | ToolDance Studio (automatic CAM and design checks) and ToolDance Controller | InfiStudio CAM |
| Warranty | 1 year | 1 year limited |
ToolDance X1 vs Makera Z1
ToolDance X1
ANNOUNCEDAnnounced Super Early Bird
- Automatic Tool Changer Capacity+ 1 workpiece probe
- 9 tools
- Optional 4-axis and 5-axis modules
- 3 axes
Makera Z1
RETAIL
Standalone · in stock in the US
- Quick tool changes
- Manual
- Optional fourth axis
- 3 axes
- Announced price gap
X1 starts $1,600 higher
- X1
- $2,999
- Z1
- $1,399 retail
- X/Y work area
X1 has about 2.7× the Z1’s X/Y work area
- X1
- 400 × 265 mm
- Z1
- 200 × 200 mm
- Tool changing
X1 changes tools automatically
- X1
- 9-tool changer
- Z1
- Manual quick-change lever
Makera Z1’s retail price is $1,600 less
If projects fit within the Z1’s 200 × 200 × 100 mm work area, its $1,399 retail price is below the X1’s announced $2,999. The X1 offers about 2.7 times the X × Y area, a 1,500 W spindle against 150 W, and automatic changes across nine tools; the Z1 pauses for a hand swap using its quick-change lever.
Price context: Z1: $1,399 standalone retail price, listed in stock in the US when checked October 1. X1: announced campaign price with final package and delivery terms still to come.
Compare all 12 specifications
| Specification | ToolDance X1 | Makera Z1 |
|---|---|---|
| Price and buying stage | $2,999 announced Super Early Bird; $2,799 for eligible VIP reservation holders after cashback; $5,999 stated MSRP. Kickstarter planned for mid-October 2026. The official campaign page remained in prelaunch, and the $30 reservation was marked out of stock, when checked October 1. Optional modules have separate crowdfunding add-on prices; final bundle and delivery terms are still to come. | $1,399 standalone retail price when checked October 1. The product page lists US stock; the selected variant is available to order. |
| Work area | 400 × 265 × 180 mm work envelope (X × Y × Z) | 200 × 200 × 100 mm |
| Spindle | Rated spindle power: 1.5 kW (S1); PMSM, up to 24,000 rpm; shanks up to 10 mm. Not specified as mechanical output power. | 150 W, up to 13,000 rpm; shanks up to 1/4 in |
| Tool changing | Automatic: 9 tools plus a workpiece probe; RFID tool identification | Manual quick-change lever |
| Probing and sensing | Spindle RGB camera and line-laser sensor, workpiece probe, and a 1080p monitoring camera | Wired probe and 3D probe rod |
| Axes | 3-axis standard; optional 4-axis module ($699) or 5-axis module ($1,099), both crowdfunding add-on prices. 5-axis development preview: workpieces up to 80 × 114 × 92 mm in 3+2 machining, or 80 × 80 × 80 mm in simultaneous 5-axis machining. | 3-axis standard; optional belt-driven 4th axis ($269); no 5-axis option |
| Cooling | Air blast standard; optional flood-cooling module ($799 crowdfunding add-on) | Built-in air blower |
| Enclosure and dust | Fully enclosed with a locking door; optional dust collection and filtration module ($499 crowdfunding add-on) | Fully enclosed; needs an external dust collector |
| Motion system | Preloaded ball screws; closed-loop NEMA 23 steppers | Acme lead screws and linear rails; open-loop NEMA 17 steppers |
| Weight and footprint | 100 kg; 750 × 625 × 772 mm | About 17 kg; 350 × 470 × 450 mm |
| Software | ToolDance Studio (automatic CAM and design checks) and ToolDance Controller | Makera Studio (public beta) and Makera App |
| Warranty | 1 year | 1 year (US) |
ToolDance X1 vs Makera Z1 Pro
ToolDance X1
ANNOUNCEDAnnounced Super Early Bird
- Automatic Tool Changer Capacity+ 1 workpiece probe
- 9 tools
- Optional 4-axis and 5-axis modules
- 3 axes
Makera Z1 Pro
RETAILShared Z1-family enclosureStandalone · in stock in the US
- Quick tool changes
- Manual
- Optional fourth axis
- 3 axes
- Announced price gap
X1 starts $1,200 higher
- X1
- $2,999
- Z1 Pro
- $1,799 retail
- Tool changing
X1 changes tools automatically
- X1
- 9-tool changer
- Z1 Pro
- Manual quick-change lever
- X/Y work area
X1 has about 2.7× the Z1 Pro’s X/Y work area
- X1
- 400 × 265 mm
- Z1 Pro
- 200 × 200 mm
The Z1 Pro adds ball screws and closed-loop motors at a lower price
At Makera’s October 1 retail price, the Z1 Pro is $1,200 less than the X1’s announced offer. It upgrades the standard Z1 with ball screws and closed-loop stepper motors while keeping the same 200 × 200 × 100 mm work area, 150 W spindle, and manual quick-change lever. The X1 adds a nine-tool automatic changer, a spindle rated at 1,500 W, and about 2.7 times the X × Y area.
Price context: Z1 Pro: $1,799 standalone retail price, listed in stock in the US when checked October 1. X1: announced campaign price with final package and delivery terms still to come.
Compare all 12 specifications
| Specification | ToolDance X1 | Makera Z1 Pro |
|---|---|---|
| Price and buying stage | $2,999 announced Super Early Bird; $2,799 for eligible VIP reservation holders after cashback; $5,999 stated MSRP. Kickstarter planned for mid-October 2026. The official campaign page remained in prelaunch, and the $30 reservation was marked out of stock, when checked October 1. Optional modules have separate crowdfunding add-on prices; final bundle and delivery terms are still to come. | $1,799 standalone retail price when checked October 1. The product page lists US stock; the selected variant is available to order. |
| Work area | 400 × 265 × 180 mm work envelope (X × Y × Z) | 200 × 200 × 100 mm |
| Spindle | Rated spindle power: 1.5 kW (S1); PMSM, up to 24,000 rpm; shanks up to 10 mm. Not specified as mechanical output power. | 150 W, up to 13,000 rpm; shanks up to 1/4 in |
| Tool changing | Automatic: 9 tools plus a workpiece probe; RFID tool identification | Manual quick-change lever |
| Probing and sensing | Spindle RGB camera and line-laser sensor, workpiece probe, and a 1080p monitoring camera | Wired probe and 3D probe rod |
| Axes | 3-axis standard; optional 4-axis module ($699) or 5-axis module ($1,099), both crowdfunding add-on prices. 5-axis development preview: workpieces up to 80 × 114 × 92 mm in 3+2 machining, or 80 × 80 × 80 mm in simultaneous 5-axis machining. | 3-axis standard; optional belt-driven 4th axis ($269); no 5-axis option |
| Cooling | Air blast standard; optional flood-cooling module ($799 crowdfunding add-on) | Built-in air blower |
| Enclosure and dust | Fully enclosed with a locking door; optional dust collection and filtration module ($499 crowdfunding add-on) | Fully enclosed; needs an external dust collector |
| Motion system | Preloaded ball screws; closed-loop NEMA 23 steppers | Ball screws and 12 mm linear rails; closed-loop NEMA 17 steppers with position-error detection |
| Weight and footprint | 100 kg; 750 × 625 × 772 mm | About 17 kg; 350 × 470 × 450 mm |
| Software | ToolDance Studio (automatic CAM and design checks) and ToolDance Controller | Makera Studio (public beta) and Makera App |
| Warranty | 1 year | 1 year (US) |
ToolDance X1 vs Carvera Air
ToolDance X1
ANNOUNCEDAnnounced Super Early Bird
- Automatic Tool Changer Capacity+ 1 workpiece probe
- 9 tools
- Optional 4-axis and 5-axis modules
- 3 axes
Carvera Air
RETAIL
Anniversary Sale Encore · regular $2,699
- Quick tool changes
- Manual
- Optional fourth axis
- 3 axes
- Announced price gap
X1 starts $700 higher
$300 above the listed regular price
- X1
- $2,999
- Carvera Air
- $2,299 sale · $2,699 regular
- Tool changing
X1 changes tools automatically
- X1
- 9-tool changer
- Carvera Air
- Manual quick-change lever
- Published spindle ratings
X1 has a 1.5 kW (S1) spindle rating
- X1
- 1.5 kW (S1) · rated power
- Carvera Air
- 200 W · basis not stated
Carvera Air’s lower price; the X1’s nine-tool automatic changes
At Makera’s October 1 sale price, Carvera Air is $700 less than the X1’s announced $2,999, or $300 less against its listed regular price. The X1 adds automatic changes across nine tools, where the Air pauses for a hand swap, plus about 1.8 times the X × Y area and a 1,500 W spindle against 200 W.
Price context: Carvera Air: $2,299 base-machine Anniversary Sale Encore price (regular $2,699), in stock when checked October 1. X1: announced campaign price with final package and delivery terms still to come.
Compare all 12 specifications
| Specification | ToolDance X1 | Carvera Air |
|---|---|---|
| Price and buying stage | $2,999 announced Super Early Bird; $2,799 for eligible VIP reservation holders after cashback; $5,999 stated MSRP. Kickstarter planned for mid-October 2026. The official campaign page remained in prelaunch, and the $30 reservation was marked out of stock, when checked October 1. Optional modules have separate crowdfunding add-on prices; final bundle and delivery terms are still to come. | $2,299 base-machine Anniversary Sale Encore price when checked October 1 (regular $2,699). In stock. |
| Work area | 400 × 265 × 180 mm work envelope (X × Y × Z) | 300 × 200 × 130 mm |
| Spindle | Rated spindle power: 1.5 kW (S1); PMSM, up to 24,000 rpm; shanks up to 10 mm. Not specified as mechanical output power. | 200 W, up to 13,000 rpm; shanks up to 1/4 in |
| Tool changing | Automatic: 9 tools plus a workpiece probe; RFID tool identification | Manual quick-change lever |
| Probing and sensing | Spindle RGB camera and line-laser sensor, workpiece probe, and a 1080p monitoring camera | Wired probe, automatic tool setter, and manual XYZ probe |
| Axes | 3-axis standard; optional 4-axis module ($699) or 5-axis module ($1,099), both crowdfunding add-on prices. 5-axis development preview: workpieces up to 80 × 114 × 92 mm in 3+2 machining, or 80 × 80 × 80 mm in simultaneous 5-axis machining. | 3-axis standard; optional 4th axis ($499); no 5-axis option |
| Cooling | Air blast standard; optional flood-cooling module ($799 crowdfunding add-on) | Optional air assist from a buyer-supplied pump; no liquid coolant option |
| Enclosure and dust | Fully enclosed with a locking door; optional dust collection and filtration module ($499 crowdfunding add-on) | Fully enclosed; needs an external dust collector |
| Motion system | Preloaded ball screws; closed-loop NEMA 23 steppers | Ball screws; closed-loop steppers |
| Weight and footprint | 100 kg; 750 × 625 × 772 mm | About 30 kg; 500 × 450 × 450 mm |
| Software | ToolDance Studio (automatic CAM and design checks) and ToolDance Controller | Makera Controller, Makera CAM, and Makera Studio (public beta) |
| Warranty | 1 year | 1 year (US) |
ToolDance X1 vs Nomad 3
ToolDance X1
ANNOUNCEDAnnounced Super Early Bird
- Automatic Tool Changer Capacity+ 1 workpiece probe
- 9 tools
- Optional 4-axis and 5-axis modules
- 3 axes
Nomad 3
RETAIL
Retail base machine
- Collet tool changes
- Manual
- Three-axis machining
- 3 axes
- Announced price gap
X1 starts $199 higher
- X1
- $2,999
- Nomad 3
- $2,800
- Tool changing
X1 changes tools automatically
- X1
- 9-tool changer
- Nomad 3
- Manual ER-11 collet
- X/Y work area
X1 has about 2.6× the Nomad 3’s X/Y work area
- X1
- 400 × 265 mm
- Nomad 3
- 203 × 203 mm
Nomad 3 costs $199 less; the X1 automates cutter swaps
Nomad 3 measures each cutter automatically after it is swapped by hand in its ER-11 collet. For $199 more, the X1’s announced offer adds a nine-tool magazine designed to handle those swaps, about 2.6 times the X × Y area, and a 1,500 W spindle against 130 W.
Price context: Nomad 3 is priced as a retail base machine. The X1 figure is an announced campaign offer; its final package and delivery terms are still to come.
Compare all 12 specifications
| Specification | ToolDance X1 | Nomad 3 |
|---|---|---|
| Price and buying stage | $2,999 announced Super Early Bird; $2,799 for eligible VIP reservation holders after cashback; $5,999 stated MSRP. Kickstarter planned for mid-October 2026. The official campaign page remained in prelaunch, and the $30 reservation was marked out of stock, when checked October 1. Optional modules have separate crowdfunding add-on prices; final bundle and delivery terms are still to come. | $2,800 retail. Ships within 14 business days. |
| Work area | 400 × 265 × 180 mm work envelope (X × Y × Z) | 203 × 203 × 76 mm (8 × 8 × 3 in) |
| Spindle | Rated spindle power: 1.5 kW (S1); PMSM, up to 24,000 rpm; shanks up to 10 mm. Not specified as mechanical output power. | 130 W brushless, 9,000–24,000 rpm; ER-11 collet |
| Tool changing | Automatic: 9 tools plus a workpiece probe; RFID tool identification | Manual ER-11 collet; a built-in BitSetter measures each new tool |
| Probing and sensing | Spindle RGB camera and line-laser sensor, workpiece probe, and a 1080p monitoring camera | BitSetter tool-length sensor and BitZero V2 probe |
| Axes | 3-axis standard; optional 4-axis module ($699) or 5-axis module ($1,099), both crowdfunding add-on prices. 5-axis development preview: workpieces up to 80 × 114 × 92 mm in 3+2 machining, or 80 × 80 × 80 mm in simultaneous 5-axis machining. | 3-axis only |
| Cooling | Air blast standard; optional flood-cooling module ($799 crowdfunding add-on) | No coolant or air assist offered |
| Enclosure and dust | Fully enclosed with a locking door; optional dust collection and filtration module ($499 crowdfunding add-on) | Fully enclosed with an interlocked door; no dust port |
| Motion system | Preloaded ball screws; closed-loop NEMA 23 steppers | Lead screws with anti-backlash nuts; NEMA 17 steppers |
| Weight and footprint | 100 kg; 750 × 625 × 772 mm | About 32 kg; 445 × 483 × 432 mm |
| Software | ToolDance Studio (automatic CAM and design checks) and ToolDance Controller | Carbide Create, Carbide Motion, and MeshCAM for Nomad |
| Warranty | 1 year | 18 months limited |
ToolDance X1 vs Nomad 4
ToolDance X1
ANNOUNCEDAnnounced Super Early Bird
- Automatic Tool Changer Capacity+ 1 workpiece probe
- 9 tools
- Optional 4-axis and 5-axis modules
- 3 axes
Nomad 4
RETAIL
Retail base machine
- Collet tool changes
- Manual
- Three-axis machining
- 3 axes
- Announced price gap
X1 starts $2,401 lower
- X1
- $2,999
- Nomad 4
- $5,400
- Published spindle ratings
X1 has a 1.5 kW (S1) spindle rating
- X1
- 1.5 kW (S1) · rated power
- Nomad 4
- 1,200 W · basis not stated
- Tool changing
X1 changes tools automatically
- X1
- 9-tool changer
- Nomad 4
- Manual ER-16 collet
Nomad 4 pairs a 1,200 W spindle with manual tool changes
The X1’s announced $2,999 is $2,401 below Nomad 4’s $5,400. ToolDance rates the X1’s spindle at 1,500 W against Nomad 4’s 1,200 W, and the X1 adds automatic changes across nine tools and about 2.1 times the X × Y area. Wattage alone cannot show which makes the better part.
Price context: Nomad 4 is priced as a retail base machine and ships by freight. The X1 figure is an announced campaign offer.
Compare all 12 specifications
| Specification | ToolDance X1 | Nomad 4 |
|---|---|---|
| Price and buying stage | $2,999 announced Super Early Bird; $2,799 for eligible VIP reservation holders after cashback; $5,999 stated MSRP. Kickstarter planned for mid-October 2026. The official campaign page remained in prelaunch, and the $30 reservation was marked out of stock, when checked October 1. Optional modules have separate crowdfunding add-on prices; final bundle and delivery terms are still to come. | $5,400 retail. Ships by freight within 20 business days; not available for international shipping. |
| Work area | 400 × 265 × 180 mm work envelope (X × Y × Z) | 254 × 203 × 89 mm (10 × 8 × 3.5 in) |
| Spindle | Rated spindle power: 1.5 kW (S1); PMSM, up to 24,000 rpm; shanks up to 10 mm. Not specified as mechanical output power. | 1,200 W VFD, 8,000–24,000 rpm; ER-16 collets up to 3/8 in |
| Tool changing | Automatic: 9 tools plus a workpiece probe; RFID tool identification | Manual ER-16 collet |
| Probing and sensing | Spindle RGB camera and line-laser sensor, workpiece probe, and a 1080p monitoring camera | BitZero V2 probe |
| Axes | 3-axis standard; optional 4-axis module ($699) or 5-axis module ($1,099), both crowdfunding add-on prices. 5-axis development preview: workpieces up to 80 × 114 × 92 mm in 3+2 machining, or 80 × 80 × 80 mm in simultaneous 5-axis machining. | 3-axis only |
| Cooling | Air blast standard; optional flood-cooling module ($799 crowdfunding add-on) | No coolant system listed |
| Enclosure and dust | Fully enclosed with a locking door; optional dust collection and filtration module ($499 crowdfunding add-on) | Fully enclosed with an interlocked door; optional dust boot |
| Motion system | Preloaded ball screws; closed-loop NEMA 23 steppers | Ball screws and HG-15 rails on every axis; NEMA 23 steppers |
| Weight and footprint | 100 kg; 750 × 625 × 772 mm | About 54 kg; 457 × 460 × 521 mm, plus an external controller |
| Software | ToolDance Studio (automatic CAM and design checks) and ToolDance Controller | Carbide Create, Carbide Motion, and MeshCAM for Nomad |
| Warranty | 1 year | 18 months limited |
Comparing ToolDance X1 with NestWorks C500, $4,699 MSRP. About 2.1 times the C500’s full X/Y travel area, a 1,500 W spindle rating, and four more tools.
Taxes, duties, and shipping vary by maker and destination. Tooling, workholding, and optional accessories may cost extra. ToolDance specifies rated spindle power of 1.5 kW (S1, continuous duty) for the X1, without identifying it as mechanical output power. InfiMaker states a maximum rating for the K1. The other listed ratings do not specify the same duty basis. These figures do not measure cutting performance on equal terms. Product imagery is not to scale.
All 9 machines in one table, with sources
| Specification | ToolDance X1 | NestWorks C500 | Makera Carvera | InfiMaker K1 | Makera Z1 | Makera Z1 Pro | Carvera Air | Nomad 3 | Nomad 4 |
|---|---|---|---|---|---|---|---|---|---|
| Price and buying stage | $2,999 announced Super Early Bird; $2,799 for eligible VIP reservation holders after cashback; $5,999 stated MSRP. Kickstarter planned for mid-October 2026. The official campaign page remained in prelaunch, and the $30 reservation was marked out of stock, when checked October 1. Optional modules have separate crowdfunding add-on prices; final bundle and delivery terms are still to come. | Manufacturer-stated MSRP: $4,699 in the ended Kickstarter. NestWorks now advertises pre-orders, but its linked store is password-protected and exposes no current checkout price. Kickstarter backers paid $2,799 to $3,199; late pledges closed July 28, 2026. | $5,299 standalone Anniversary Sale Encore price when checked October 1 (regular $5,799). Available to order; confirm shipping timing with Makera. | $5,699 late-pledge price (stated MSRP $9,499), with estimated delivery February 2027. The $5,199 Super Early Bird offer ended September 26. | $1,399 standalone retail price when checked October 1. The product page lists US stock; the selected variant is available to order. | $1,799 standalone retail price when checked October 1. The product page lists US stock; the selected variant is available to order. | $2,299 base-machine Anniversary Sale Encore price when checked October 1 (regular $2,699). In stock. | $2,800 retail. Ships within 14 business days. | $5,400 retail. Ships by freight within 20 business days; not available for international shipping. |
| Work area | 400 × 265 × 180 mm work envelope (X × Y × Z) | 240 × 210 × 130 mm full XYZ travel. The tool magazine reduces usable X/Y area; NestWorks’ product page publishes conflicting installed-magazine dimensions. | 360 × 240 × 140 mm | 220 × 160 × 180 mm XYZ travel; largest 5-axis workpiece 120 × 120 × 120 mm | 200 × 200 × 100 mm | 200 × 200 × 100 mm | 300 × 200 × 130 mm | 203 × 203 × 76 mm (8 × 8 × 3 in) | 254 × 203 × 89 mm (10 × 8 × 3.5 in) |
| Spindle | Rated spindle power: 1.5 kW (S1); PMSM, up to 24,000 rpm; shanks up to 10 mm. Not specified as mechanical output power. | 800 W, 9,000–18,000 rpm; shanks up to 1/4 in | 200 W, up to 15,000 rpm; shanks up to 1/4 in | 1.5 kW (maximum rating), up to 20,000 rpm; 4 and 6 mm shanks in the changer | 150 W, up to 13,000 rpm; shanks up to 1/4 in | 150 W, up to 13,000 rpm; shanks up to 1/4 in | 200 W, up to 13,000 rpm; shanks up to 1/4 in | 130 W brushless, 9,000–24,000 rpm; ER-11 collet | 1,200 W VFD, 8,000–24,000 rpm; ER-16 collets up to 3/8 in |
| Tool changing | Automatic: 9 tools plus a workpiece probe; RFID tool identification | Automatic: 5 tools; RFID tool holders | Automatic: 6 tools | Automatic: 5 tools plus a probe station | Manual quick-change lever | Manual quick-change lever | Manual quick-change lever | Manual ER-11 collet; a built-in BitSetter measures each new tool | Manual ER-16 collet |
| Probing and sensing | Spindle RGB camera and line-laser sensor, workpiece probe, and a 1080p monitoring camera | 3D touch probe, automatic tool setter, probing camera, and laser distance sensor | Wireless probe for Z, tool length, and leveling; manual XYZ probe | Wireless 3D touch probe for centering and 5-axis calibration | Wired probe and 3D probe rod | Wired probe and 3D probe rod | Wired probe, automatic tool setter, and manual XYZ probe | BitSetter tool-length sensor and BitZero V2 probe | BitZero V2 probe |
| Axes | 3-axis standard; optional 4-axis module ($699) or 5-axis module ($1,099), both crowdfunding add-on prices. 5-axis development preview: workpieces up to 80 × 114 × 92 mm in 3+2 machining, or 80 × 80 × 80 mm in simultaneous 5-axis machining. | 3-axis standard; optional 4th axis ($699 MSRP); no 5-axis option | 3-axis standard; optional 4th axis ($599); no 5-axis option | Simultaneous 5-axis included (B axis −30° to +110°, C axis 360°) | 3-axis standard; optional belt-driven 4th axis ($269); no 5-axis option | 3-axis standard; optional belt-driven 4th axis ($269); no 5-axis option | 3-axis standard; optional 4th axis ($499); no 5-axis option | 3-axis only | 3-axis only |
| Cooling | Air blast standard; optional flood-cooling module ($799 crowdfunding add-on) | MQL mist standard; air blast with a buyer-supplied compressor; no flood option | Optional air assist from a buyer-supplied compressor or pump; no liquid coolant option | Optional InfiFlow water coolant; water-cooled spindle | Built-in air blower | Built-in air blower | Optional air assist from a buyer-supplied pump; no liquid coolant option | No coolant or air assist offered | No coolant system listed |
| Enclosure and dust | Fully enclosed with a locking door; optional dust collection and filtration module ($499 crowdfunding add-on) | Fully enclosed with an interlocked door (IP54); auger chip evacuation and a vacuum port | Fully enclosed; built-in dust collection | Fully enclosed with a locking door; chip tray, no dust-collection port | Fully enclosed; needs an external dust collector | Fully enclosed; needs an external dust collector | Fully enclosed; needs an external dust collector | Fully enclosed with an interlocked door; no dust port | Fully enclosed with an interlocked door; optional dust boot |
| Motion system | Preloaded ball screws; closed-loop NEMA 23 steppers | Ball screws and linear rails; closed-loop NEMA 23 steppers | Ball screws; closed-loop servo motors | Preloaded ball screws and linear guides; servo motors | Acme lead screws and linear rails; open-loop NEMA 17 steppers | Ball screws and 12 mm linear rails; closed-loop NEMA 17 steppers with position-error detection | Ball screws; closed-loop steppers | Lead screws with anti-backlash nuts; NEMA 17 steppers | Ball screws and HG-15 rails on every axis; NEMA 23 steppers |
| Weight and footprint | 100 kg; 750 × 625 × 772 mm | About 120–130 kg; 550 × 615 × 745 mm | About 50 kg; 580 × 520 × 540 mm | About 166 kg with the production cast-iron bed; 560 × 700 × 800 mm | About 17 kg; 350 × 470 × 450 mm | About 17 kg; 350 × 470 × 450 mm | About 30 kg; 500 × 450 × 450 mm | About 32 kg; 445 × 483 × 432 mm | About 54 kg; 457 × 460 × 521 mm, plus an external controller |
| Software | ToolDance Studio (automatic CAM and design checks) and ToolDance Controller | NestStudio with automatic toolpaths; accepts standard G-code | Makera Controller and Makera CAM; Makera Studio is in public beta. Built-in 2.5 W laser. | InfiStudio CAM | Makera Studio (public beta) and Makera App | Makera Studio (public beta) and Makera App | Makera Controller, Makera CAM, and Makera Studio (public beta) | Carbide Create, Carbide Motion, and MeshCAM for Nomad | Carbide Create, Carbide Motion, and MeshCAM for Nomad |
| Warranty | 1 year | 12 months on main components | 1 year (US) | 1 year limited | 1 year (US) | 1 year (US) | 1 year (US) | 18 months limited | 18 months limited |
ToolDance X1
NestWorks C500
Makera Carvera
InfiMaker K1
Makera Z1 Pro
The team behind ToolDance
Led by founder and CEO Will Wang, ToolDance describes a team with experience at DJI and Siemens across robotics, precision manufacturing, and consumer electronics. Company announcement ↗ ToolDance brief ↗
The company reports five generations of X1 prototypes and 150 units in continuous testing, with another 200 planned. Supplied brief ↗
ToolDance introduced the X1 at IFA Berlin, held September 4–8, 2026. IMTS listed ToolDance among Xsurge Technology Inc.’s brands for its September 14–19 show in Chicago, and Maker Faire Bay Area listed a ToolDance exhibit for September 25–27. Company announcement ↗ Official event records ↗
Kickstarter planned for mid-October 2026
ToolDance says the X1’s Kickstarter launch is planned for mid-October 2026, with no specific date confirmed. When checked October 1, the company advertised a $2,999 Super Early Bird starting price against a stated $5,999 MSRP, or an effective $2,799 starting price for eligible VIP buyers after cashback. Its separate $30 advance reservation is described as refundable, but the reservation page was marked out of stock when checked October 1. Its Kickstarter page remained in prelaunch. VIP buyers still pledge the full campaign amount; ToolDance says the cashback and deposit refund are processed separately after the campaign. Company announcement ↗ ToolDance brief ↗ ToolDance’s launch details ↗
ToolDance has confirmed the optional-module crowdfunding prices listed above. Final bundle contents, shipping charges, and delivery details are still to come.
I’m excited by the project possibilities: custom metal brackets, wooden molds, acrylic panels, and fixtures that make the next build easier. The X1’s automatic tool changes, along with its optional 4-axis and 5-axis modules, make it an interesting addition to the desktop CNC market.
See the X1 on ToolDance’s websitePaid sponsor link. ToolDance’s website has its current specifications and launch terms.
ToolDance X1 questions, answered.
What the X1 includes, what the Studio demonstrations show, and where I still want hands-on answers. These notes draw on ToolDance’s supplied information and the sources in this feature.
How much will the ToolDance X1 cost, and when does it launch?
ToolDance’s Kickstarter launch is planned for mid-October 2026, with no specific date confirmed. As of October 1, 2026, the announced Super Early Bird price starts at $2,999; eligible VIP reservation holders can reach $2,799 after cashback. The separate $30 reservation was marked out of stock. Final campaign terms and delivery details are still to come.
ToolDance X1 VIP reservation terms · ToolDance product clarifications
See current price and launch statusWhat is included in the $2,999 X1 price?
The $2,999 figure is the announced starting price for the base three-axis X1. The optional 4-axis module is $699 and the optional 5-axis module is $1,099; dust collection and flood cooling are also separate. These are US-dollar crowdfunding add-on prices confirmed September 28. Final bundle contents, shipping charges, and delivery timing still need confirmation.
ToolDance product clarifications · ToolDance X1 VIP reservation terms
See what is confirmed and still openHow does the ToolDance X1 compare with the Carvera Air?
At prices checked October 1, 2026, the X1’s announced $2,999 starting price is $700 above Carvera Air’s $2,299 sale price. The main distinction is tool changing: X1 lists a 9-tool automatic changer that follows the programmed job, while the Air uses manual quick changes. X1’s announced campaign offer and Air’s available retail machine also have different buying and delivery terms.
X1 market comparison and manufacturer sources
Compare X1 and Carvera Air in detailWhat does the X1's 1.5 kW (S1) spindle rating mean?
ToolDance specifies rated spindle power of 1.5 kW (S1), with a maximum speed of 24,000 RPM. The company has not specified that figure as mechanical output power. I’m treating it as a manufacturer rating; cutting performance and finished-part quality will need testing with actual tools, materials, and setups.
ToolDance product clarifications · ToolDance IFA 2026 announcement
Read the spindle and material detailsWhat materials can the ToolDance X1 machine?
ToolDance lists steel, stainless steel, titanium, aluminum, brass, copper, hardwood, acrylic, and other plastics as supported materials. That offers a broad range of project possibilities. The practical setup still depends on the cutter, stock, workholding, feeds and speeds, and cooling. I haven’t tested the X1 on these materials.
ToolDance product clarifications · ToolDance X1 public product page · ToolDance IFA 2026 announcement
See the material and cooling contextHow many tools does the X1 hold, and does it change them automatically?
The X1 is specified to store and automatically change among 9 cutting tools, with a separate workpiece probe. For a job with pockets, holes, and finished edges, the machine can switch between the programmed cutters without each manual swap. The operator still needs to load the correct tools, secure the stock, and supervise machining.
ToolDance X1 public product page · ToolDance IFA 2026 announcement · ToolDance X1 media kit
See how the tool-change sequence worksHow large a part can the X1 machine, and how much shop space does it need?
ToolDance specifies a 400 × 265 × 180 mm XYZ work envelope. Its published weight and machine dimensions are 100 kg; 750 × 625 × 772 mm. Fixtures, cutters, and optional rotary modules reduce the room available for a particular part. The materials I reviewed do not give service-clearance dimensions. Bench planning also needs to allow for access and any separate cooling or dust equipment.
ToolDance X1 media kit · ToolDance X1 public product page · ToolDance IFA 2026 announcement
See the work-envelope illustrationIs the ToolDance X1 a three-axis, four-axis, or five-axis CNC?
3-axis standard; optional 4-axis module ($699) or 5-axis module ($1,099), both crowdfunding add-on prices. 5-axis development preview: workpieces up to 80 × 114 × 92 mm in 3+2 machining, or 80 × 80 × 80 mm in simultaneous 5-axis machining. The smaller module workpiece dimensions should not be confused with the base machine’s XYZ work envelope.
ToolDance product clarifications · ToolDance X1 VIP reservation terms
See the optional axis modulesAre flood cooling and dust collection included with the X1?
Air blast is standard. ToolDance lists flood cooling at $799 and dust collection and filtration at $499 as optional US-dollar crowdfunding add-ons, separate from the base machine. Those are campaign add-on prices confirmed September 28, rather than retail prices. Choose the configuration around the material and work you plan to machine.
ToolDance product clarifications
See cutting and chip-management detailsCan I import a model and machine it with ToolDance Studio?
ToolDance Studio brings design checks, automatic toolpaths for supported jobs, simulation, and workholding guidance into one preparation workflow. In the supplied videos I reviewed, a person still positions and secures the stock. That looks like a useful move toward simpler CNC setup, but it does not establish one-click machining for arbitrary models.
ToolDance X1 public product page · ToolDance IFA 2026 announcement · ToolDance Studio demonstrations · ToolDance X1 media kit
Watch the supplied AutoCAM demonstrationIs ToolDance Studio included, and does it require a subscription?
ToolDance hasn’t confirmed Studio’s license price, subscription terms, supported operating systems, or offline and cloud requirements in the materials I’ve reviewed. The demonstrations explain its intended workflow, but they don’t establish these purchase terms. Those are useful details to confirm when the campaign and software terms are published.
ToolDance X1 public product page · ToolDance X1 VIP reservation terms · ToolDance X1 media kit
See what the Studio demos establishWhat files can Studio import, and can X1 use Fusion 360 or other CAM?
ToolDance’s supplied brief describes STEP and STL import. Its public X1 page also names compatibility with Fusion 360, Siemens NX, and Mastercam. I haven’t tested that connection, and the materials I reviewed do not document the exact postprocessor or project-transfer procedure. ToolDance Studio’s own workflow and third-party CAM compatibility should be evaluated separately.
ToolDance X1 media kit · ToolDance X1 public product page · ToolDance Studio demonstrations
Read the Studio workflow contextDoes ±0.01 mm repeatability mean every finished part will be accurate to ±0.01 mm?
ToolDance states ±0.01 mm positioning repeatability: how consistently the machine returns to a position under the same conditions. That is different from a guaranteed tolerance for every finished part. Cutter deflection, workholding, material, toolpaths, calibration, and measurement also affect the result. I would want measured test parts before making a finished-part accuracy claim.
ToolDance IFA 2026 announcement · ToolDance X1 media kit · NIST measurement terminology
Read the positioning-specification noteHas The Crafty Catsman tested the ToolDance X1?
I reviewed ToolDance’s supplied specifications, media, written clarifications, and software demonstrations, and checked public sources for the market comparison. I haven’t tested the X1 or Studio firsthand. ToolDance paid for this feature. I hope to have the opportunity to test the complete workflow and share what I learn in a future update.
ToolDance X1 media kit · ToolDance product clarifications · ToolDance Studio demonstrations · ToolDance X1 public product page · ToolDance IFA 2026 announcement
Review the evidence and disclosureSpecifications are manufacturer claims; demonstrations are not independent tests. Each answer links to the supporting source notes and the relevant chapter. Download the facts and source notes (JSON).
Sources and product details
Prepared September 16, 2026. Updated September 18 with observations from ToolDance’s supplied Studio demonstrations, and September 23 with ToolDance’s preferred product terminology, additional supplied images, the AutoCAM demonstration video, updated event details, a check of ToolDance’s Kickstarter pre-launch page and specification table, and a recheck of every machine, specification, and price in the market comparison. Updated September 28 with ToolDance’s confirmed module dimensions, crowdfunding add-on prices, launch window, spindle-rating wording, and a review of current competitor prices, buying stages, and past event dates. Published September 30 after a final review of offer prices, buying stages, and reservation availability. Updated October 1 with new Makera prices and a fresh check of competitor offers, reservation availability, and event wording. Added a sourced buyer-question reference on October 1, drawn from the same specifications, supplied demonstrations, and pricing records as the feature. Product specifications and development figures are attributed to ToolDance. Event details were checked against organizer listings.
- ToolDance X1 media kit
Supplied September 16, 2026: six-page product brief, specifications, development history, software description, optional modules, and launch information. Product renderings and IFA photographs are supplied by ToolDance. Additional renderings, a 5-axis module image, and a campaign graphic were supplied September 23, 2026, when ToolDance also resent its AutoCAM demonstration for use in this article.
- ToolDance product clarifications
Written confirmation received September 28, 2026: 5-axis module workpiece dimensions and development-preview status; US-dollar crowdfunding add-on prices of $699 for the 4-axis module, $1,099 for the 5-axis module, $499 for dust collection, and $799 for flood cooling; copper support; a Kickstarter launch planned for mid-October 2026; and rated spindle power of 1.5 kW (S1), without a mechanical-output specification. ToolDance also confirmed the AutoCAM demonstration should remain muted.
- ToolDance Studio demonstrations
Visual review of four short videos supplied by ToolDance: AutoCAM Programming, DFM Analysis, Workholding Guidance System, and From Image to Model. Reviewed September 18, 2026. The AutoCAM demonstration appears in the Studio chapter without sound. These are company demonstrations; I haven’t tested Studio or the X1 firsthand.
- Studio compatibility and public product details
ToolDance’s X1 product page, reviewed October 1, names compatibility with Fusion 360, Siemens NX, and Mastercam, and describes design checks, workholding guidance, and image-to-model tools. These are manufacturer descriptions; the workflow has not been tested here.
- Autodesk Fusion documentation
Create a setup (Fusion Manufacture help), used to explain stock, fixtures, and work coordinates.
- Measurement terminology
Renishaw’s accuracy, resolution, and repeatability definitions, used for context when reading the positioning specification. NIST’s measurement terminology also distinguishes repeatability from accuracy.
- Company announcement
ToolDance’s September 4 announcement, distributed by PR Newswire. This is a company-issued statement.
- Official event records
IFA’s ToolDance exhibitor profile; IMTS’s exhibitor listing, whose exhibitor of record, Xsurge Technology Inc., lists ToolDance among its brands; and Maker Faire Bay Area’s ToolDance exhibit listing. These document the September exhibitor listings. The organizers published the 2026 dates for IFA (September 4–8), IMTS (September 14–19), and Maker Faire Bay Area (September 25–27).
- Kickstarter pre-launch page
ToolDance’s X1 pre-launch page on Kickstarter, which showed Kickstarter’s “Project We Love” badge and no launch date when checked September 23, 2026.
- Public product and reservation terms
ToolDance’s product site and VIP reservation page, consulted September 16, with the advertised prices and reservation availability rechecked October 1, 2026. Pricing and campaign terms may change.
- Market comparison sources
Manufacturer store pages, specification tables, manuals, and campaign pages for each machine in the comparison, with specifications checked September 23, 2026 and prices and buying stages reviewed October 1. Sources are listed beneath the full comparison table. The K1 has a $5,699 late-pledge offer. Makera’s October 1 standalone prices replace the September offers: $5,299 for Carvera, $2,299 for Carvera Air, $1,399 for Z1, and $1,799 for Z1 Pro. NestWorks still does not expose a public checkout price, so the C500 is labeled with its historical stated MSRP.
